Binocular/Trinocular Observation Head

  • Observation head inclined at 45° rotatable at 360°.
  • Diopter adjustment ring on ocular tube (±5).
  • Interpupillary distance from 55mm to 75mm.

Eyepiece

  • Wide field 10X (paired) F.O.V. 20mm.

Zooming Range & Ratio

  • Zoom 0.7X to 4.5X with magnification ratio of 1:6.4

Working Distance

  • 100 mm.

Mechanical Body

  • Track stand with fan type base.
  • Lateral zoom control movement.
  • Clip for holding specimen.
  • Base size is 198mm X 250mm.

Magnification Range

  • 7X – 45X

Illumination System

  • Incident and transmitted light systems with LED lamps.
  • Both lights are regulated with power supply and has separate brightness controls.
