Technical Specification

Objectives :  5X , 10x, 20x  & 40x
Eyepiece :  WF 10 x (paired)
Magnification : 50x to 400x.
Filter : Green, Blue

  • Binocular Siedentop inclined at 30 degree.
  • Phototube for micro photography.
  • Diopter adjustment ring on ocular tube.Interpupillary distance from 55mm to 75mm.
  • Co-axial focusing system with large knobs, pre-focusing lever & tension adjustment ring
  • Reverse Angle quadruple nosepiece on ball bearing.
  • Mechanical stage.
  • The Mechanical stage has low positioned co-axial controls on ball bearing guide ways. Hand rests on both sides.

Optional Accessories

  • Digital USB Microscopy Camera
  • Metallurgical Image Analysis Software

Features

  • Co-axial and fine focusing system with slide traveling on ball bearing guide ways.
  • Inner locating ball bearing nosepiece.
  • Observation on trinocular head, compensation(inclined 30degrees)
  • Triple plate for X and Y movement of workstage.
  • Anti-fungal coated objectives.
  • Illumination unit 6V 20W halogen lamp, adjustable brightness…
