Feature
- High resolution & high quality image.
- Real time preview and focusing.
- Image refresh rate up to 30fps, choosing ROI will be more.
- USB2.0 design makes it easy to carry and install.
- Extra adapter is unnecessary with standard C-mount optical interface.
- Plug-to-use, suitable for shooting of any standard biological, stereo and metallurgical microscopes.
- 12-bit color depth for outstanding color fidelity.
- Peltier cooled to 10 C below ambient.
- Exposure times ranging from 0.1 ms to 200 ms.
- Automatic exposure and white balance. Manual mode for fine tuning.
- Standard C-MOUNT is widely used in connection between microscope and camera.
- 1/1.8″Sony ICX252 Progressive Scan Interline CCD, good quality guarantee.
Specifications
- Sensor – 1/1.8″ Sony ICX252 CCD, 5 megapixels
- Resolution – 2048 X 1536, 12bit
- Pixels Size – 3.45μm X 3.45μm
- Frame Rate – 5fps@2048 X 1536, 30fps@640 X 480
- Binning – 2×3,3×3 or 4×4,color
- Shutter – Electronic shutter
- S/N Ratio – 72dB
- Cooling Type – Peltier cooling
- Exposure – 0.1 ms-200ms
- Scanning Mode – Progressive scanning
- Operating Temp – -30°C ～60°C
- Spectral Response – 400nm～1000nm
- White Balance – One-push auto, manual
- Optical Interface – Standard C-Mount
- Software Functions – Image preview, acquisition, video record, measuring, image processing Data Interface – USB2.0, 480Mbit/s
- OS – Windows 2000, XP SP2/SP3, Vista; USB2.0 Port
