Feature
- 3.1 megapixels with progressive scanning CMOS image sensor.
- No compression, no interpolation.
- Support still image capture (JPG,BMP)
- USB 2.0 interface, up to 480MPS, external power no need.
- Interfaced to a computer via USB2.0 technology for rapid image download.
- Plug-to-use, suitable for shooting of any standard biological, stereo and metallurgical microscopes.
- Ease of operation; only take 5 minutes to master the friendly software.
- Standard C-Mount makes connection to any microscope easy. Macro lens setups are also supported
- Fully integrated package with digital camera and imaging software for managing your imaging work flow.
- Data can be shared, stored and edit, real-time preview function offers you the greatest experience with the microscope.
- Video taping is available, simple to store and transfer when compression mode is selected
Specifications
- Sensor – 2.0M CMOS
- Resolution – 1600×1200(8bit)
- Pixels Size – 3.4μm×3.4μm
- Frame Rate – 10fps@1600×1200; 30 fps@640 ×480
- Shutter – Electronic
- S/N Ratio – 43 dB
- Scanning Mode – Progressive scanning
- Sensitivity – 1.0 V/ lux-sec (550nm)
- Data Interface – USB2.0 (480 Mbit / sec)
- Power Supply – DC 5V ± 5%
- Electricity – ≈200 mA
- White Balance – Auto one-touch
- Exposure control – 10μs–32ms,Auto exposure
- Software – Display/Film/Video
- Operating Temp – 0°C ~ 60°C
